EOD suit
Product specification Structure: it is composed of helmet, mask, chest protector, back protector, arm protector, neck protector, shoulder protector, leg protector, crotch protector, hand protector and foot protector Material: the coat is made of nomex fire-retardant cloth, the chip bulletproof layer is made of arylamide woven fabric, including neck (back) 17 layers, arm, back, leg (back) 22 layers, crotch, neck (front) and shoulder for 26 layers, chest for 32 layers, leg (front) 39 layers, ha...
- Category
- EOD Equipment
- Application
- See the product overview for application and configuration details.
- Service
- OEM/ODM and technical support available
- Inquiry
- Specifications available on request
Product Structure
Components: Helmet, visor, chest, back, arm, neck, shoulder, leg, groin, hand and foot protection.
Materials: Nomex flame-resistant outer fabric and woven aramid ballistic layers: 17 layers at the rear neck; 22 at the arms, back and rear legs; 26 at the hip, front neck and shoulders; 32 at the chest; 39 at the front legs; and 18 at the hands and footwear.
Armor inserts: 8 mm PE plate combined with 8 mm silicon carbide.
Helmet: Shell and suspension cushioning system; the shell uses 13.0 mm aramid material.
Visor: 22 mm ballistic composite glass.
Product Advantages
Comprehensive heavy-duty protection covers the head, neck, torso, chest, back, waist, abdomen and limbs. Multiple composite layers attenuate blast waves, intercept high-speed fragments and protect against heat, flame and impact, reducing serious injury risks from nearby explosions.
Intelligent hearing protection: The EOD helmet combines sound pickup, noise reduction and impulse-noise protection. It attenuates loud blast noise while amplifying speech and subtle environmental sounds, and supports two-way communications.
Ergonomic operation: Flexible reinforced joints support squatting, kneeling, climbing and bending while maintaining protection for precise close-range EOD work.
Integrated ventilation: Powered helmet ventilation replaces hot internal air, reducing discomfort during prolonged wear and improving comfort and endurance in hot conditions.
Emergency quick release: A dedicated rapid-removal system allows the suit to be removed quickly when hazards arise or the wearer is injured, supporting timely first aid and evacuation.
Durable construction: Abrasion-, tear- and corrosion-resistant flame-retardant outer materials and stable internal protection layers support repeated use in complex indoor and outdoor hazardous environments.
V50 ballistic-limit test results against 1.1g cylindrical wedge-shaped fragment-simulating projectiles under normal temperature and humidity conditions
Helmet V50 ballistic limit: 642m/s
Visor V50 ballistic limit: 793m/s
Neck protection V50 ballistic limit (including insert): >992m/s
Chest protection V50 ballistic limit (including insert): >2134m/s
Groin protection V50 ballistic limit (including insert): >1043m/s
V50 ballistic limit: 540m/s
V50 ballistic limit: 527m/s
Front-leg protection V50 ballistic limit: 667m/s
V50 ballistic limit: 555m/s
Applications
Police and armed-police EOD duties: Close-range investigation, disassembly and transfer of suspicious packages, improvised explosive devices and abandoned hazardous explosive items.
Airports, high-speed railway and metro stations, and ports: Professional response to unexpected explosive hazards and suspicious devices.
Major sports events, exhibitions, official gatherings and busy public squares: Emergency response and advance EOD protection.
Border and field operations: Locating and clearing unexploded ordnance and abandoned blasting equipment in mountainous and other difficult terrain.
Emergency-management response: Explosive-hazard handling, emergency intervention and rescue after explosive incidents.
Military and police EOD training, emergency drills and specialized tactical instruction.
